Purpose
Two well-known weaknesses of the Flexo printing process can be eliminated by X!Mask: Avoiding of hard edges and unsteady image with unsatisfactory color density in solid areas causing „pinholing“ or „mottling“.
Main functions
The lasered surface in full-tone and mid-tone areas is structured by superimposing a user-defined bitmap structure. The distance between the imposed structure and the edge of an area can is defined as a parameter. Highlights and small positive vector elements, below a defined threshold, are supported during the UV imaging process by raising the bottom of the plate locally. The two functions are independent of each other. Standard TIFF data are analysed and adapted on the fly during imaging.
